EP 400 - AWC Model

  • Auto sampling of 1st layer tablet in bi layer mode
  • Complete recipe management, data acquisition and control with Audit trail
  • 4 level of PASSWORD control for different user level with different rights
  • “TOOL SAFE” Overload System
  • Auto hard tablet sampling of the 1st layer
  • Precise tracking of punch movement with encoder
  • Individual Servo motor for fill depth control for 1st and 2nd layer fill depth and 1st layer and 2nd Layer tablet compression force control
  • 15'' HMI Panel as operator Interface

General Specification

  • Turret with Electroless Nickel Plating for corrosion resistance
  • Double Paddle Force Feeder with Clockwise & Counter Clockwise rotation of paddles
  • Compression rollers tonnage capacity of 20kN/2Tons for Pre 100kN/10Tons for Main
  • Segmented type double walled Cams design for easy Maintenance & change over
  • Tool-less HOPPER Stainless Steel (SS-316) fitment with tri-clover joint with Powder Control Valve
  • PULL DOWN CAM Alloy Steel (EN353) for reduced dust generation during upper punch entry
  • BI-LAYER attachment with Online Auto Sampling of 1st layer thru' touch screen (Optional)
  • 'TOOL SAFE' overload system (Optional)
