EP 400 – AFR Model


  • Defective tablet identification by force measurement
  • Compression & Ejection Force Measurement with Load Cell
  • Auto sampling of 1st layer tablet in bi layer mode
  • Auto hard tablet sampling of the 1st layer
  • Load cell for Pre Compression force measurement
  • Load cell for Main Compression force measurement
  • 15.0'' Touch screen as Operator Interface with force display for each punch during each rotation
  • The integrated control panel includes :
    • Mode Selector Switch for SETUP / OFF / RUN
    • START / STOP Switches/JOG
    • Emergency Stop

General Specification

  • Turret with Electroless Nickel Plating for corrosion resistance
  • Double Paddle Force Feeder with Clockwise & Counter Clockwise rotation of paddles
  • Compression rollers tonnage capacity of 20kN/2Tons for Pre 100kN/10Tons for Main
  • Segmented type double walled Cams design for easy Maintenance & change over
  • Tool-less HOPPER Stainless Steel (SS-316) fitment with tri-clover joint with Powder Control Valve
  • PULL DOWN CAM Alloy Steel (EN353) for reduced dust generation during upper punch entry
  • BI-LAYER attachment with Online Auto Sampling of 1st layer thru' touch screen (Optional)
  • 'TOOL SAFE' overload system (Optional)
