• Ideally suited for Large volume production
• AHCOS – Auto Hydraulic Compression Overload System
• Internal Helical Drive to the Turret through high torque reduction gear box
• Main & Feeder Motor control through AC Variable Frequency Drive
• Large capacity motor ensures no jerks/slippages even when compressing large tablets
• The Automatic Startup / Stop Tablet Rejection for segregation of tablets produced during initial & final stage of the batch
• Swing Arm mounted Control Panel with SMART Touch Screen HMI includes: Emergency Stop, Mode Selector Switch for RUN / OFF / SETUP
• Storage & recall of 100 Recipes

General Specification

• Precision machined Electroless Nickel Plated Turret with & lower punch seal
• Three stage Paddle Force Feeder with Clockwise & Counter Clockwise rotation of paddles
• Compression rollers tonnage capacity of 100kN/10Tons for Main Compression & 20kN/2Tons for Pre Compression
• Variable Upper Punch Penetration for main Compression 1.0 to 7.0mm. for Single Layer & 2.0 to 7.5mm for Bi-Layer
• Double walled Cams design for easy maintenance & change over
• SS 316 Hopper with Powder Controlling Gate Valve
• Tablet Parameter Control from side of the machine through Controlling Knobs
• SS 316 Two Way Discharge Chute for Tablet Production
