• Ideally suited for Large volume production
• Fully cGMP compliant Tablet Press in robust four pillar construction
• AHCOS – Auto Hydraulic Compression Overload System
• Internal Helical Drive to the Turret through high torque reduction gear box
• Main & Feeder Motor control through AC Variable Frequency Drive
• Large capacity motor ensures no jerks/slippages even when compressing large tablets
• The Automatic Startup / Stop Tablet Rejection for segregation of tablets produced during initial & final stage of the batch
• Storage & recall of 100 Recipes

General Specification

• Precision machined Electroless Nickel Plated Turret with & lower punch seal
• Double Paddle Force Feeder with Clockwise & Counter Clockwise paddle rotation
• Compression rollers tonnage capacity of 100kN/10Tons for D Tooling & 65kN/6.Tons for B & BB Tooling
• Variable Upper Punch Penetration 1.0 to 7.0mm. for Single Layer & 2.0 to 7.5mm for Bi-Layer
• Double walled Cams design for easy maintenance & change over
• SS 316 Hopper with Powder Controlling Gate Valve
• Tablet Parameter Control from side of the machine through Dial gauges for Compression & Fill Depth control
• SS 316 Two Way Discharge Chute for Tablet Production
