• Kiosk mounted Control 15.0'' Touch screen as Operator Interface with force display for each punch during each rotation
• Defective tablet identification by force measurement
• Compression Force Measurement with Load Cell
• Initial Rejection function enables the tablets to diverted through the gate into rejection chute during every Start & Stop of the Machine
• Parameters setting like Turret Speed, Force Feeder Speed, Auto Lubrication, Safety Interlocks, Hydraulic Compression and many more

General Specification

• Precision machined Electroless Nickel Plated Turret with & lower punch seal
• Double Paddle Force Feeder with Clockwise & Counter Clockwise paddle rotation
• Compression rollers tonnage capacity of 100kN/10Tons for D Tooling & 65kN/6.Tons for B & BB Tooling
• Variable Upper Punch Penetration 1.0 to 7.0mm. for Single Layer & 2.0 to 7.5mm for Bi-Layer
• Double walled Cams design for easy maintenance & change over
• SS 316 Hopper with Powder Controlling Gate Valve
• Tablet Parameter Control from side of the machine through Dial gauges for Compression & Fill Depth control
• SS 316 Two Way Discharge Chute for Tablet Production
