• Auto weight control function by force measurement
• Servo driven control for Weight, pre thickness and main thickness
• Ejection and take off force measurement
• Auto identification of Fill track
• 21 CFR part 11 compliance for all function of Panel PC/HMI
• Electro magnetic clutch in main drive for smooth startup during full compression load and hand wheel side for easy hand rotation during change over
• Minimal dust generation during compression
• Auto hard tablet sampling of the 1st layer
• Individual Servo motor for fill depth control for 1st and 2nd layer fill depth
• Individual servo motor for 1st layer and final tablet compression force control
• 15'' HMI Panel for Operating the machine

General Specification

• Turret with Electroless Nickel Plating for corrosion resistance
• Alluminum Hard Anodized force Feeder with Independent ACVFD
• Compression rollers tonnage capacity of 100kN/10Tons for Pre and 100kN/10Tons for Main
• Tool-less HOPPER Stainless Steel (SS-316) fitment with tri-clover joint with Powder Control Valve
• PULL DOWN CAM Alloy Steel (EN353) for reduced dust generation during upper punch entry
• 'TOOL SAFE' overload system
• Direct drive to the turret through a High torque reduction gear box
• Discharge Chute with Good, Sample & Reject Tablet Production
