• GMP model with 20 & 27 station in “D” & “B” tooling
• Electro magnetic clutch for heavy duty application
• ACVF Drive for the main motor
• High torque motor for better tablet compression
• Ideal for Effervescent tablets/Veterinary/Non pharma applications
• Sturdy center pillar construction to withstand high load application
• 25mm diameter round tablet compressed with ease

General Specification

• Precision machined Electroless Nickel Plated Turret with lower punch seal
• Aluminum Hard Anodized Gravity Feeder
• Compression rollers tonnage capacity of 100kN/10tons for D & 65kN/6.5Tons B & BB Tooling
• Variable Upper Punch Penetration 1.5 to 8.0mm
• PULL DOWN CAM Alloy Steel (EN353) for reduced dust generation during upper punch entry
• Turret drive through robust external worm & worm gear system
• Tablet Parameter Control from out side of the machine through Controlling Knobs
• Sturdy center pillar construction to withstand high load application
